PostgreSQL - Automatic Data Lineage

What to Expect

Views(/data-sources/sql-parser/)

Dataedo analyzes SQL scripts defining database views with built-in SQL Parser and builds column-level lineage from tables/views to views queried by them. To learn more about parsing PostgreSQL dialect visit: PostgreSQL Parsing.

Stored Procedures

Dataedo will create column-level data lineage for stored procedures based on the script. The script will be divided into steps represented as separate processes. Data lineage will be created only for supported steps, the unsupported steps will be named after the first word from the process script and end with three dots. This is seen on the data lineage configuration tab in Desktop.

Known Limitations

1. Check the limitations for views lineage from SQL parser
2. Check the limitations for stored procedures lineage from SQL parser

Troubleshooting

I don't see data lineage for views

1. Make sure you have selected the right SQL dialect - in this case PostgreSQL (SQL Dialect field at Data Source level).

2. Rerun import of the source - maybe the schema was imported in an older version or the configuration was incorrect.

I don't see data lineage for stored procedures

1. Make sure Dataedo supports the SQL syntax of the procedure. Check Known Limitations above.

2. Rerun import of the source - maybe the schema was imported in an older version or the configuration was incorrect.

Cross database lineage is not built

1. Make sure the source object has Linked Source with correctly assigned database.

2. Rerun import of the source - maybe the schema was imported in an older version or the configuration was incorrect.
